Dometic Heki 2 Skylight with Blind 960 x 655mm

Description

Dometic Skylight Heki 2 960mm x 655mm. The Heki 2 rooflight, made from robust and weatherproof ASA, was developed especially for caravans.

The mounting kit is sold separately. Select a Heki 2 kit for your roof thickness from the related products below: 25-32, 32-39, 39-46, 46-53 or 53-60 mm.

In strong sunlight, keep the blackout blind no more than two-thirds closed and put the dome in its continuous-ventilation position to prevent damaging heat build-up between the blind and dome.

Features

• The double-glazed acrylic panel is easily opened with the metal bar handle, as the panel is held open by the pneumatic stays for your comfort.
• Three opening positions: fully open, half-open and continuous ventilation. Close the rooflight in rain or snow, do not open it in strong wind, and close and lock it before travelling.
• The large opening of approx. 780 x 530 mm allows plenty of light and also optimal ventilation.
• Easy installation along or across the vehicle roof. The roller flynet and blind are mounted to the inner frame, which can be adjusted independently or combined.
• Permanent ventilation allows airflow even with the dome closed.
• 1 year warranty.

Specifications

• Manufacturer Part Number: ELE11272527
• Brand: Seitz
• Roof cut-out: 960 mm x 655 mm
• Internal frame dimensions: 1000 mm x 700 mm
• Installation requires a flat surface area of 1080 x 780 mm
• Suitable roof thickness: 25-60 mm with the appropriate mounting kit, sold separately
• Maximum opening angle: 55°
• Height above roof when closed: approximately 105 mm
• Frame colour: cream white (RAL 9001)
• Shipping Weight: 15.00 Kgs.
• Shipping Dimensions: 22 cm x 80 cm x 120 cm.

Further Information

• View the related PDF: Dometic Heki 2 Skylight with Blind Manual
• View the related PDF: Dometic Heki 2 Skylight Technical Drawing
• View the related PDF: Dometic Heki 2 Skylight with Blind Repair Instructions

Our Comments

Don't forget to also purchase the most suitable mounting kit.
