Thetford Access Door 5 White / 305 x 755mm Cut-Out

Description

The Thetford Service Door 5 is a lockable external access hatch for caravan and motorhome luggage spaces or water-tank compartments. It has two locking push-button latches, with the section cut from the vehicle wall trimmed and fitted into the door frame as the matching infill panel.

Install it horizontally in a flat side wall with the hinges at the bottom. It is not designed for installation in the vehicle front, roof or floor.

Features

• UV-resistant plastic construction
• Double-seal design and rain diverter help protect the compartment from the weather
• Two locking push-button latches provide secure closure
• 1 year warranty.

Specifications

• Manufacturer Part Number: 2682484
• Brand: Thetford
• Barcode: 8710315615074
• Application: General luggage or water-tank access door
• Nominal catalogue cut-out size: 755 x 305 mm
• Manufacturer template cut-out: 749 x 297 mm; use the supplied template for final marking and cutting
• Main external dimensions: 786 x 344 mm
• Clear door opening: 730 x 280 mm
• Suitable wall thickness: 23-39 mm
• Mounting orientation: Horizontal only, with hinges at the bottom
• Mounting surface: Flat vehicle side wall; not suitable for the front, roof or floor
• Door infill: Not supplied separately; made from the cut-out wall panel
• Locking points: 2
• Shipping Weight: 2.19 Kgs.
• Shipping Dimensions: 5 cm x 35 cm x 80 cm.
