Description
The Dometic RM2350 is a 90-litre absorption fridge/freezer for built-in installation in caravans and motorhomes. Its quiet, vibration-free refrigeration system operates on 12 V DC, 240 V AC or LPG, with the energy source selected manually using the top-mounted controls. Gas operation uses push-button piezo ignition.
Use 12 V cooling only while the vehicle engine is running: the heating element runs continuously without thermostat control and can quickly discharge a parked vehicle's battery. Select LPG or 240 V when parked. Do not operate on LPG while travelling, and turn off the gas bottle. Level the vehicle when parked with the fridge operating to prevent loss of cooling.
The cabinet cut-out is only part of the installation: the fridge needs a lower outside air intake, an upper outlet and a flue connection, with the combustion system sealed off from the vehicle interior. The ventilation system is not included. The door accepts a decorative panel to match your interior; panel dimensions are listed below.
Features
Flexible, removable shelving options
Manual energy selection (MES) for fuel versatility
Magnetic door seals for secure closure
User-friendly control panel at the top
Customisable door panel to match interiors
Automatic flame failure safety device
Travel catch holds the door closed during travel
3 year warranty.
Specifications
Manufacturer Part Number: RM2350
Other Identifier: RM2350-936004121
Brand: Dometic
Barcode: 6951218426585
Operates on: 12 V / 240 V / Gas
Energy Source Selection: Manual (MES)
Overall Capacity: 90 L
Freezer Capacity: 11 L
Overall Dimensions (mm): 556 (w) x 766 (h) x 577 (d)
Cut-out Required (mm): 521 (w) x 756 (h) x 542 (d)
Hinge: Right (hinge reversal kit included)
Weight: 29 kg
Gas Consumption: 13.5 g/h
Gas Connection: 1/8 inch BSP female fitting
Gas Supply: Universal LPG at 2.75 kPa
12 V Heating Element: 175 W
12 V Supply Wiring: minimum 6 mm² conductors and a 20 A fuse in the positive lead; ignition-controlled relay required to disconnect cooling power when the ignition is off
Decorative Door Panel Dimensions: 496-498 mm wide x 665-667 mm high; maximum thickness 4 mm
