Thetford Access Door 6 Black / 419 x 997mm Cut-Out

Description

The black Thetford Service Door 6 creates a wide exterior access opening for large luggage or storage compartments. It suits a 419 x 997 mm wall cut-out and provides a 400 x 980 mm clear opening.

The section removed from the vehicle wall is trimmed and fitted into the door frame as the exterior panel, helping it match the surrounding wall finish.

Features

• Three lockable push-button latches provide secure closure.
• UV-resistant plastic frame with double seals and a rain diverter.
• 1 year warranty.

Specifications

• Manufacturer Part Number: 2686427
• Brand: Thetford
• Barcode: 8710315008593
• Colour: Black
• Application: Wide general luggage or storage access door
• Overall frame (short x long): 465 x 1038 mm
• Required cut-out (short x long): 419 x 997 mm
• Clear opening (short x long): 400 x 980 mm
• Suitable wall thickness: 23-39 mm
• Installation position: Flat side wall, mounted horizontally with the hinges at the bottom
• Not suitable for roof, floor or vehicle-front installation
• Panel insert: Not supplied; trim the section removed from the vehicle wall to fit the door frame
• Shipping Weight: 3.34 Kgs.
• Shipping Dimensions: 5 cm x 48 cm x 105 cm.
