Float-Side Repair Kit Suits Lippert In-Wall Slide-Outs

Description

Repair kit for the float-side mechanism of a Lippert In-Wall slide-out. For this kit, the float side is the right-hand side when standing outside the RV and facing the slide-out room; it does not refer to the vehicle's normal right side.

The float assembly can be identified by its plastic bearing-block rivet, which is designed to shear and allow limited alignment movement. MPN 330484 is the corresponding fixed-side kit.

Features

• 1 year warranty.

Specifications

• Manufacturer Part Number: 330485
• Brand: Lippert
• Application: Lippert In-Wall slide-out system
• Side configuration: Float side
• Viewing reference: Right-hand side when standing outside the RV and facing the slide-out room
• Kit contents: Upper gear rack, lower gear rack, V-roller, snap ring, shoe, foam wear plug and flat-back rack plug
• Not included: Coupler, upper or lower bearing blocks, metal or plastic rivets, or spur gear
• Gear racks are supplied overlength and are cut to match the original rack length
• Shipping Weight: 3.50 Kgs.
• Shipping Dimensions: 11 cm x 11 cm x 112 cm.
