Spare Parts Diagram - RM7401 Fridge Controls

Spare Parts Diagram - RM7401 Fridge Controls
Spare Parts Diagram - RM7401 Fridge Controls
Key Link Model/Name
2412796035
Connection wiring,electronic,terminal board,MES/AESII
26
2412788503
Light conductor,Control panel
26
2412788511
Light conductor,Control panel
227K
7295279017
Screw,zinc-plated,RXS,B6X10
401
2412933109
Control panel,plastic,DOM, L=525mm, MES
401 View 2412933505
Control panel,plastic,bent,L=523, DOM, MES
401
2412933570
Control panel,complete,plastic,RAL7021,DOM,L=523mm
402
2412787000
Turning knob,silver-grey
402 View 2412787208
Turning knob,grey
402
2412787273
Turning knob,selector switch,temperature,RAL 7021
418
2926202009
Bracket,for,gas connection
421B View 2412798205
Gas valve,HEA TEC GV100
421B View 2412798353
Gas valve,with,gas connection,Australia
425
2412593507
Gas inlet pipe,complete,D=4,75/0,7x493mm
425
2412593556
Gas inlet pipe,complete,D=4,75/0,7x483mm, SE
425
2412593572
Gas inlet pipe,complete,D=4,75/0,7 x 509 mm
429A
2412423606
Gas connection,D=8/1x80mm
430B
2413986031
Gas connection,with,union nut,AUSTRALIA
446 View 2413229408
Heater,235V/135W
446 View 2951694302
Heater,service,12V/130W
446
2952170401
Heater,230V/135W
458
2927903100
Union nut,M14x1,5
474A
2412796308
Connection wiring,burner control device,electronic
477
2923191007
Filter,for,gas connection
486C View 2412784106
Shaft,selector switch,black,MES
486C
2412784304
Shaft,selector switch,light grey,MES
487C View 2412785004
Shaft,temperature,grey
487C
2412785103
Shaft,temperature,yellow
493 View 2952248504
Temperature probe,L=1100mm
515A
2412786002
Fixing bracket,for,electronic
521
2412789006
Ignition,HEA TEC P810
521 View 2412789105
Ignition,service,HEA TEC P810
521 View 2412789303
Burner control device
522
2412769008
Cabinet,lower part,electronic
523A View 2412771103
Electronic,complete,MES, FE104
524
2412770006
Cabinet,top part,electronic
569
2106424233
Connection wiring,black,CEE, L=2000mm
569
2106424936
Connection wiring,connection,black,CHATEAU, L=1750mm
569
2935659439
Connection wiring,black,L=2500mm, AUSTRALIA
569
2951879739
Connection wiring,black,13A/3A, L=2500mm
Show RM7401 Fridge Diagrams
Show All RM7401 Fridge Diagrams
4 Diagrams
