Spare Parts Diagram - Dometic RUC8408 Fridge
| Key | Link | Model/Name |
|---|---|---|
| 2 |  |
4450016600 BUSH HINGE RUA/RUC |
| 3 |  |
4450016593 STRIP DECOR RUA/RUC |
| 4 |  |
4450016599 COVER HANDLE HOLE RUA/RUC |
| 5 | |
4450019721 Cardboard Insert Freezer Door |
| 6 |  |
4450016973 PANEL DECOR FREEZER RUA/RUC |
| 7 |  |
4450017032 SHELF DOOR UPPER RUA/RUC |
| 8 |  |
4450016383 RETAINER BOTTLE RUA RUC |
| 9 |  |
4450016603 HOLDER BOTTLE RUA/RUC |
| 10 |  |
4450017034 SHELF DOOR LOWER RUA/RUC |
| 11 |  |
4450016637 GASKET DOOR FREEZER RUA/RUC |
| 19 |  |
46-065-30MZ MAGNET DOOR RUA/RUC |
| 20 | |
4450019720 Cardboard Insert Fridge Door |
| 21 |  |
4450016974 PANEL DECOR FRIDGE RUA/RUC |
| 23 |  |
4450016636 GASKET DOOR FRIDGE RUA/RUC |
| 24 |  |
4450017047 SHELF WIRE FREEZER RUA/RUC |
| 26 |  |
4450016379 HINGE LOWER RUA/RUC |
| 27 |  |
4450016627 CAP FIXING SCREW RUA/RUC |
| 28 |  |
4450016391 SHELF CABINET FRZ RUA/RUC |
| 29 |  |
4450016623 PLUG/RETAINER SHELF RUA/RUC |
| 34 |  |
4450016384 HINGE MIDDLE RUA/RUC |
| 35 | |
4450016607 HOUSING DISPLAY RUA/RUC |
| 36 | |
4450016385 PIN HINGE MIDDLE RUA/RUC |
| 37 |  |
4450016612 COVER HINGE PIN RUA/RUC |
| 39 |  |
4450017309 PCB DISPLAY RUCPCB DISPLAY RUC |
| 40 |  |
4450016639 PANEL CONTROL RUA/RUC |
| 41 | |
4450016609 BUTTON CONTROL RUA/RUC |
| 42 | |
4450016819 ELEMENT DEFROST RUA/RUC |
| 47 |  |
4451004271 THERMISTOR RU/RUC |
| 48 |  |
4450016786 FAN INTERNAL RUA/RUC |
| 50 | |
4450017520 LIGHTAND VENT INTERNAL RUA/RUC |
| 52 |  |
2930693045 CLIP RETAINER BAR RM2453/2553 |
| 53 |  |
4450016390 SHELF CABINET UPPER RUA/RUC |
| 54 |  |
4450016389 RETAINER WIRE RUA/RUC |
| 55 |  |
4450016388 SHELF CABINET MIDDLE RUA/RUC |
| 60 |  |
4450017587 SHELF CHRISPER RUA/RUC |
| 61 |  |
4450016618 DIVIDER CHRISPER RUA/RUC |
| 62 |  |
4450016617 CRISPER RUA/RUC |
| 64 |  |
4450016378 HINGE UPPER RUA/RUC |
| 66 | |
4450016619 COVER HINGE HOLE RUA/RUC |
| 67 |  |
4450016624 TRIM BOTTOM RUA/RUC |
| 71 | |
11-00-A1225M12B FAN RPD RPD/RUC |
| 72 |  |
10-05-GR75LQ DRIER FILTER7G CF/CDF/CFX |
| 74 | Search | 10-01-ACV25DC11 COMPRESSOR RPD/RUC/CFX95 |
| 76 | |
4450017272 CONTROL UNIT COMPRESS RUC |
| 78 |  |
4450017220 PCB MAIN RUC8408/6408 |
| 84 |  |
4450017243 HOSE DRAIN RUA/RUC/6408 |
| 88 |  |
4450017584 DOOR FRIDGE RUA/RUC 8408 |
| 89 | |
4450017604 HANDLE LH FRIDGE RH FRZ RUA/RUC |
| 90 | |
4450017605 HANDLE RH FRIDGE LH FRZ RUA/RUC |
| 117 |  |
4450016787 DEFROST SENSOR |
